Chondrite H5 Sahara 97095.

  [ Back  :   Home ]

Polished section of a chondrite H5 with an oblique fiber optics illumination. The opaque minerals appear dark on this image. Nice chondrule at the top left. Click for another view of this meteorite with the same illumination.

Same illumination as in preceding picture. Chondrules are not so clearly defined.

Thin section of a chondrule in LPNA. The magnification has been increased (10X objective).

Same view of the chondrule in LPA.
